AFX-D2 DUAL HF DRIVER

Description

Experience exceptional clarity, power, and precision with this high-performance neodymium compression driver, engineered for professional audio systems and high-frequency reproduction. Designed for superior sound quality and durability, it delivers powerful output and smooth frequency response — ideal for concert speakers, line arrays, and professional sound reinforcement setups.

Key Features

• Throat Diameter: 1.5″ (38 mm)

• Mounting Type: 4 × M6 Holes at 90° on an 82.5 mm diameter pattern for secure installation

• Nominal Impedance: 2 × 16 Ohm configuration for flexible system integration

• Power Handling (AES): 160W total (2 × 80W above 1 kHz) for high output and reliability

• Sensitivity:

  • 2 × 1W/1m: 105 dB

  • 1W/1m/2.83V: 102 dB

• Frequency Response: 1,000–20,000 Hz — delivering crisp, accurate highs

• Voice Coil: Dual 3″ (76.2 mm) Kapton formers for heat resistance and stability

• Magnet Material: High-strength neodymium for lightweight power and efficiency

• Diaphragm Material: Durable polyester for smooth, detailed sound reproduction

Ideal For

Line Array Systems | Professional PA Systems | Touring Sound | Concert Speakers | High-Frequency Replacements
